Fi BSPT Branch Tee Hydralulic Fittings
Fòm: Tee
Fil 1 Kalite: Fi BSPT
Fil 2 Kalite: Fi BSPT
Fil 3 Kalite: Fi BSPT
Fi BSPT Branch Tee
Nimewo Pati:
A7T
Atribi:
Materyèl: Steel
Fòm: Tee
Fil 1 Kalite: Fi BSPT
Fil 2 Kalite: Fi BSPT
Fil 3 Kalite: Fi BSPT
T1 | T2 | T3 | Pati No | E | F | G | S1 | |||
Dash | BSPT | Dash | BSPT | Dash | BSPT | mm | mm | mm | mm | |
-02 | 1/8-28 | -02 | 1/8-28 | -02 | 1/8-28 | A7T-020202 | 20 | 20 | 20 | 19 |
-04 | 1/4-19 | -04 | 1/4-19 | -04 | 1/4-19 | A7T-040404 | 23 | 23 | 23 | 19 |
-06 | 3/8-19 | -06 | 3/8-19 | -06 | 3/8-19 | A7T-060606 | 26 | 26 | 26 | 24 |
-08 | 1/2-14 | -08 | 1/2-14 | -08 | 1/2-14 | A7T-080808 | 31 | 31 | 31 | 27 |
-12 | 3/4-14 | -12 | 3/4-14 | -12 | 3/4-14 | A7T-121212 | 34 | 34 | 34 | 33 |
-16 | 1-11 | -16 | 1-11 | -16 | 1-11 | A7T-161616 | 42 | 42 | 42 | 41 |
-20 | 1.1/4-11 | -20 | 1.1/4-11 | -20 | 1.1/4-11 | A7T-202020 | 48 | 48 | 48 | 50 |
-24 | 1.1.2-11 | -24 | 1.1.2-11 | -24 | 1.1.2-11 | A7T-242424 | 53 | 53 | 53 | 60 |
-32 | 2-11 | -32 | 2-11 | -32 | 2-11 | A7T-323232 | 62 | 62 | 62 | 70 |
Fitting tib 24 degre oswa "Bite-Type" se fitting ki pi popilè globalman epi anplwaye sistèm tiyo ki pi avanse nan mond lan.
Sistèm sa a kapab kenbe tèt ak presyon ki wo ak vibrasyon ekstrèm, gras a konsepsyon bag koupe a.
Bag la koupe se yon ferrule ki enkòpore kwen koupe byen file. Lè yon nwa se torqued sou Fitting an, baz nwa a antre an kontak ak bag la koupe, kwense l 'nan gòj la 24 degre conique nan Fitting an kidonk koupe nan ak grip tib la.
Baj popilè: fi bspt branch tee idwolik ekipman, Lachin, manifaktirè, wholesale, nan stock, te fè nan peyi Lachin
